Panduit BSV14X-L Butt Splice, Vinyl Insulated, 16 - 14 AWG Wire Range, Blue, 0.211" Max Insulation, 1.04" Length (Pack of 50)

This Panduit BSV14X-L vinyl-insulated butt splice connector is suitable for repairing or extending solid or stranded copper wires from #16 to #14 AWG (1.5 to 2.5 sq. mm). It has a tin-plated copper body with a vinyl housing for electrical and thermal insulation, a maximum voltage rating of 600V, and a maximum temperature rating of 221 degrees F (105 degrees C). This connector has a brazed seam for protecting the barrel from splitting during the crimping process, an internal wire stop for ensuring the proper insertion depth of stripped conductors, and has a barrel color coded in blue to match Panduit color-coded dies. It is Restriction of Hazardous Substances (RoHS) compliant for hazardous substance regulations and is Underwriters Laboratories (UL) Listed and Canadian Standards Association (CSA) certified for quality assurance. This vinyl-insulated butt splice connector is suitable for use with solid and stranded copper wires from American Wire Gauge (AWG) #16 to #14 (1.5 to 2.5 sq. mm) in a wide range of industrial, automotive, and other electrical applications.SpecificationsConnector typeButt splice, insulatedFor use with solid and stranded copper wire#16 to #14 AWG (1.5 to 2.5 sq. mm)Color codeBlueCompatible with Panduit crimping toolsCT-100A, CT-600-A, CT-1550, CT-1551, CT-2500Length1.04" (26.42 mm)Maximum wire insulation diameter0.2" (5.08 mm)Body materialTin-plated copperBody material thickness0.03"Insulation materialVinylMaximum voltage rating600VMaximum temperature rating221 degrees F (105 degrees C)Flammability ratingUL 94V-0Standards metUL Listed, CSA certified, RoHS compliantPanduit manufactures electrical and networking products. The company, founded in 1955, is headquartered in Tinley Park, Il.

• Vinyl-insulated butt splice connector for repairing or extending solid or stranded copper wires from #16 to #14 AWG (1.5 to 2.5 sq. mm)
• Tin-plated copper body with vinyl housing for electrical and thermal insulation
• Maximum voltage rating of 600V
• Maximum temperature rating of 221 degrees F (105 degrees C)
• UL Listed and CSA certified for quality assurance, RoHS compliant for hazardous substance regulations
